Honing Tubes

Honing Tubes

European Special Alloys W.L.L. specializes in high-quality cold-drawn seamless honing tubes, ideal for hydraulic cylinders and other precision applications. Manufactured from premium St52 BK+S (E355 SR) steel, our tubes undergo stress-relief heat treatment post-cold drawing to ensure dimensional stability and uniformity.

We offer two types of honing tubes:

• Ready for Honing Tubes: Inner diameter tolerance of -0.2 mm to -0.3 mm.
• Ready for Burnishing Tubes: Inner diameter tolerance of -0.6 mm to -0.9 mm.

All tubes are cold drawn, heat-treated, and straightened to a maximum deviation of 1 mm per meter, ensuring high precision and quality.

Standard Specifications:

Diameter Range	Standard Length	Surface Roughness (Ra)	Oil Preservation
50 mm to 400 mm	6 m – 9 m (up to 14 m upon request)	0.4 µm – 0.8 µm	Oiled for 6 months to prevent oxidation

Available Diameters:

Outer x Inner Diameter (mm)	Outer x Inner Diameter (mm)	Outer x Inner Diameter (mm)
40 x 50	60 x 75	115 x 130
50 x 60	60 x 80	120 x 135
50 x 65	70 x 80	120 x 140
60 x 70	70 x 85	120 x 145
60 x 75	70 x 90	125 x 140
60 x 80	75 x 90	125 x 150
70 x 80	80 x 90	130 x 150
70 x 85	80 x 95	130 x 160
70 x 90	80 x 100	140 x 160
75 x 90	90 x 105	140 x 170
80 x 90	90 x 110	140 x 175
80 x 95	100 x 115	150 x 170
80 x 100	100 x 120	150 x 180
90 x 105	100 x 125	160 x 180
90 x 110	110 x 125	160 x 185
100 x 115	110 x 130	160 x 190
100 x 120	115 x 130	170 x 200
100 x 125	120 x 135	180 x 200
110 x 125	120 x 140	180 x 210
110 x 130	120 x 145	190 x 215
115 x 130	125 x 140	200 x 220
120 x 135	125 x 150	200 x 230
120 x 140	130 x 150	200 x 245
120 x 145	130 x 160	220 x 245
125 x 140	140 x 160	220 x 270
125 x 150	140 x 170	250 x 280
130 x 150	140 x 175	250 x 300
130 x 160	150 x 170	280 x 325
140 x 160	150 x 180	300 x 350
140 x 170	160 x 180	320 x 377
140 x 175	160 x 185	350 x 400

Additional Offerings:

• Circuits Pipes for Oil Transfer: Manufactured from St37.4 seamless steel tubes, normalized after cold drawing for easy bending without cracking. Available in various sizes ranging from 6x1 mm to 42x3 mm.
